6 Series

New!

Overview

Efficiency Redefined.

Made in Germany, the Series 6 stands out for its superior reliability, comfort and low operating costs. The family’s models – from 6160 Powershift to 6230 TTV HD – are equipped with the tried-and-true TCD 6.1 engine with maximum power and torque of up to 230 HP and 970 Nm. The tractors can be equipped with basic Powershift, fully automatic shifting RCshift or advanced stepless TTV transmissions with unprecedented smoothness and ride comfort. As a distinctive advantage, the 6210 TTV, 6230 TTV, and 6230 TTV HD offer the option of impressive 50 kph maximum speed.

Main Specifications

161-230 HP

6-cylinder

Weight of 7200-10325 Kg

Wheelbase of 2767-2918 mm

Engine

Peak power with low maintenance requirements. Series 6 six cylinder tractors are equipped with water-cooled, single turbocharged TCD engines. The updated TCD 6.1 engines guarantee increased performance at even lower rpm, with tangible improvements in both torque curve and elasticity. All in all resulting in a smoother and more effective operation. In addition, with almost all the maximum torque available at just 1000 rpm, these tractors can tackle most tasks at low engine speeds, thereby ensuring significant fuel savings. Furthermore, completely new fuel tanks have been developed for all models. Combined with low fuel consumption and a capacity of up to 505 liters (on 6230 TTV HD), extremely long operating times are possible. The use of cutting-edge manufacturing techniques has enabled the production of engines characterised by extremely precise manufacturing tolerances. As a result, the engine oil change interval for the Series 6 tractors has been extended to 1000 operating hours (or 2 years).

Engine	Deutz TCD 6.1 Stage V
Rated / Max. Horsepower	155-225/171-230
Cylinder Displacement	6 l
Common Rail Fuel Pressure	1600 bar
Max Torque	698-796 Nm
Fuel Capacity	350-505 l
DEF (AdBlue) Capacity	29-35 l

Do
NOT DELETE
THIS TABLE
IT CREATES CSS THAT IS USED
in the ACF Repeater
JET Engine fields
for the engine specs - Ken
DEF (AdBlue) Capacity

Cab / Operations

MaxiVision cab family. We understand that comfort and convenience are vital for long hours in the field. These DEUTZ-FAHR tractors boast ergonomic and spacious MaxiVision cabs with state-of-the-art controls and user-friendly interfaces. Enjoy reduced fatigue, increased visibility and intuitive operation for an enhanced overall tractor driving experience. The cabs of the MaxiVision family are composed of three variants: MaxiVision, MaxiVision+ and MaxiVisionPro.

Driveline

Select the right gearbox for your business. At DEUTZ-FAHR, we believe that you know best which transmission variant suits your needs. That’s why we offer three transmission variants for the 6 Series: Powershift, RCshift and TTV. All three offer simple operation, high efficiency and exceptional driving comfort.

Transmission

Drive your implements with maximum efficiency.

Unique in the market is the DualSpeed front PTO. With the DualSpeed option, 1000 and 1000 ECO PTO speeds can be changed from inside the cab in the InfoCentrePro. This allows maximum operating efficiency at all times and means that it is possible to operate with 1000 PTO or 1000 ECO PTO in the front and the rear. This results in significant reduced fuel consumption, less wear of the moving parts and low noise in the cab due to the right PTO speed depending on field conditions. At the rear, four PTO speeds 540/540ECO/1000/1000ECO are in standard equipment for the Powershift and RCshift models as well as TTV models up to 190 hp. The TTV models from 6190 TTV - 6230 TTV HD offer three PTO speeds. All models offer maximum versatility and the highest performance when using different equipment. To quickly and efficiently adapt the tractor to any implement, all models fit the very useful removable PTO output shaft as standard.

Hydraulics

Unlock full potential with the modular hydraulic system of Series 6

One of the design targets for the development of the Series 6 was maximum versatility for efficient pairing with the widest range of implements. For the hydraulics, there is a choice between mechanical and electro-hydraulic controls and up to five hydraulic valves in the rear and two in the front in addition to the control of front linkage. The optional Load Sensing hydraulic pump output reaches up to 210 l/min while the rear lift capacity is up to 10 t. The front linkage system of the 6 Series range is available in four variants. 6160.4 – 6180 have a maximum capacity of 4110 kg while 5450 kg are possible on the 6190, 6210 and 6230 models. In addition an efficient front lift version with 3800 kg capacity is available for all models. The brand-new load relief control for the front linkage can be equipped for the first time in the TTV models up to 6180 TTV. Thanks to the new option, the contact pressure of the front implement can be adjusted and the weight can be transferred to the front axle in all situations. This means that there is always sufficient grip available and the sensitive ground as well as the machine is reliably protected. The pressure is infinitely adjustable from 1 – 100 bar even during operation.
